Brother PJ883
| General | |
| Carton contents | USB Cable (Type A-Type C) Quick Start Guide Cleaning Sheet |
| Language support | Dansk, Deutsch, English, Español, Français, Italian, Nederlands, Norsk, Português, Suomi, Svenska |
Description
|
Wi-Fi security
|
Authentic method (encryption scheme) |
| Infrastructure mode: | |
| Open system(None/WEP64/WEP128） | |
| Common key authentication (WEP) | |
| WPA/WPA2-PSK/WPA3-SAE (TKIP+AES) | |
| WPA3-SAE (AES) | |
| EAP-FAST (TKIP/AES) | |
| PEAP (TKIP/AES) | |
| EAP-TLS (TKIP/AES) | |
| EAP-TTLS (TKIP/AES) | |
| TLS 1.0/1.1/1.2/1.3 | |
| Authentic method (encryption scheme) | |
| Wireless direct mode: | |
| WPA2-PSK (AES) | |
| WPS (Wi-Fi Protected Setup) | |
| 802.11i |
| Printer commands | Raster graphic |
| ESC/P Brother(ESC/P_B) | |
| P-touch Template | |
| ZPL II emulation |
|
Internal fonts & sizes
|
Bitmap font: Gothic (16, 24, 32dot), Letter |
| Gothic Bold, Helsinki (16, 24, 32, 48dot), | |
| Brussel, San Diego, Brougham (24, 32, | |
| 48dot) | |
| Outline font: Gothic, Letter Gothic, Helsinki, | |
| Brussel (Max: 400dot) | |
| <P-touch Template> | |
| Outline font: Gothic, Letter Gothic, Helsinki, | |
| Brussel (Max: 400dot) | |
| <ZPL II emulation> | |
| Bitmap font: “A”,”B”,”C”,”D”,”E”,”F”,”G”,”H” | |
| Outline font: “0” | |
| Memory | RAM: 256 MB |
| Flash:64 MB (User area: 30 MB) |
|
Internal Barcode
|
Linear: <Common> |
| CODE39, ITF(I-2/5), EAN-8(JAN8), EAN- | |
| 13(JAN13), UPC-A, UPC-E, CODABAR(NW- | |
| 7), CODE128, GS1-128(UCC/EAN-128), | |
| POSTNET, GS1 DataBar (RSS) | |
| <Additional ESC/P mode> | |
| CODE93, UPC/EAN EXTENSION, MSI, | |
| Intelligent Mail Barcode | |
| <Additional P-touch Template mode> | |
| Intelligent Mail Barcode | |
| <Additional ZPL II mode> | |
| CODE93, UPC/EAN EXTENSION, MSI, | |
| Intelligent Mail Barcode, Industrial 2-of-5, | |
| Standard 2-of-5 | |
| 2D : | |
| <Common> | |
| QR Code, PDF417, MaxiCode, Aztec | |
| <Additional ESC/P mode> | |
| Micro QR Code, MicroPDF417, DataMatrix | |
| <Additional P-touch Template mode> | |
| GS1 Databar Composite, Micro QR Code, | |
| MicroPDF417, DataMatrix | |
| <Additional ZPL II mode> | |
| GS1 Databar Composite, MicroPDF417, | |
| DataMatrix |
| Optional Accessories | |
| Paper Handling | PA-RH-600 Paper roll holder |
| PA-PG-003 Paper guide (PJ-822/823) | |
| PA-PG-004 Paper guide (PJ-862/863/883) | |
| AC mains adapter | PA-AD-003EU USB Type-C 2-pin EU plug |
| PA-AD-003UK USB Type-C 3-pin UK plug | |
| Battery | PA-BT-002 |
|
Carry case
|
PA-CC-500 Protective carry case |
| PA-RC-001 Roll printer case (IP54 rated) | |
| PA-RB-001 Rubber protective cover | |
|
Car power adapter
|
PA-CD-600CG Cigarette lighter plug (15v) |
| PA-CD-600WR Permanently wired (15v) | |
| Vehicle mount | PA-CM-500 |
|
1 Under Brother standard test conditions, using A4 size with JAITA J1
|
|
| pattern (1.9% coverage) at a temperature of 23 degrees C, via USB | |
| using Li-ion battery with full charge or AC adapter. | |
| 2 PJ-883 only. | |
| 3 Option – PA-BT-002 | |
| 4 Font Licensee permissions are required | |
| 5 For additional supplies information, please contact your local | |
| Brother office |
| Wi-Fi security | |
| Dimensions & Weights | |
|
Without carton
|
255mm(w) x 55mm(d) x 30mm(h) |
| 610 g with battery3 | |
| 480 g with dummy battery | |
| 430 g without battery |
| Built In Features | |
| Printing Method | Direct Thermal |
|
Print Resolution
|
PJ-822 | PJ-862 : |
| PJ-823 | PJ-863 | PJ-883 : 300dpi | |
| Maximum print speed | 13.5ppm1 |
| Maximum print width | 203.2mm |
| Maximum print length | 279.4mm |
|
Minimum media width
|
Cut sheet 148 mm (A5 |
| Roll paper 210 mm (A4) | |
|
Maximum media width <ESC/P>
|
Cut sheet 215.9 mm (Letter/Legal) |
| Roll paper 215.9 mm (Letter/Legal) | |
| Media thickness | 0.16mm or less |
| Media sizes | A4, A5, Letter, Legal, continuous |
|
Media types
|
Paper and Synthetic |
| Full-page: Cut Sheet, Continuous Roll, | |
| Perforated Roll, Fan-Fold | |
| Labels: Cut Sheet, Fan-Fold | |
| Battery capacity (option) | 1,750mAh |
| Battery yield (option) | Approx. 600 A4 sheets1 |
| Battery charging time | 2 hours (using optional power adapters) |
|
Interfaces
|
All models: |
| USB Ver.2.0 (Full Speed) (Type C) | |
| PJ-862 | PJ-863 | PJ-883 : | |
| Bluetooth v5.2 (Classic + BLE) | |
| NFC (for pairing – Android only) | |
| PJ-883 : | |
| Wireless LAN IEEE802.11a/b/d/g/i/n | |
| supporting 2.4GHz and 5GHz bands | |
|
Bluetooth profile Linear:
|
SPP, OPP, HCRP (Bluetooth Classic), GATT |
| (Low Energy), iAP supported | |
|
Operating system support
|
Microsoft® Windows® 8.1 / 10 / 11 |
| / Server 2012 / Server 2012R2 / Server | |
| 2016 / Server 2019 / Server 2022 | |
| macOS 10.15 / 11 / 12 | |
| Linux Red Hat and Debian | |
|
Windows SDK
|
Microsoft® Windows® 7 / 8.1 / 10 |
| / Server 2012 / Server 2012R2 / Server 2016 | |
| / Server 2019 | |
|
Mobile SDK
|
Android v8 or later |
| iOS v11 or later^ | |
| ^^Supports Bluetooth communication from | |
| ver. 12.2 or later. | |
| Requires 3rd party app development using | |
| Brother SDK. Further information available at | |
| https://support.brother.com/g/s/es/dev/en/ind | |
| ex.html?c=eu |
|
Software
|
P-touch Editor – Barcode label design |
| software | |
| Brother Print Service Plugin – Driverless | |
| printing from Android devices (version 5.0 | |
| and above) | |
| Mobile Deploy App – Remote printer | |
| configuration | |
| Brother Font Manager – Font download tool | |
| (Windows® only via USB)4 | |
| Printer Settings Tool – Device configuration | |
| software (Windows® only via USB) | |
| BRAdmin Pro 4 – Device management | |
| (Windows® only) | |
| Environmental | |
| Operating Temperature | Printing with Battery/Car Adapter : -10°C to |
| 50°C | |
| Printing with AC Adapter : -10°C to 40°C | |
| Charging : 0°C to 40°C | |
| Operating Humidity | 20% to 80% non-condensing |
| Storage Temperature | -20ºC to 60º C |
| Storage Humidity | 10% to 90% non-condensing |
| Supplies | |
| Media type5 | Cut sheet paper : PA-C-411 (A4 100 sheets) |
| Roll Paper: PA-R-411 A4 width/100 sheets at | |
| A4 length (6 rolls per box) |
