| Depth of Field EAN 13 (13mil) |
70mm-610mm |
| Depth of Field Code 39 (5mil) |
110mm-290mm |
| Depth of Field PDF417 (6.7mil) |
110mm-230mm |
| Depth of Field DataMatrix (10mil) |
110mm-260mm |
| Depth of Field QR (15mil) |
55mm-410mm |
| Performance |
| Operating System |
Android 13 GMS |
| Processor |
2.0GHz Octa-Core 64-bit Processor |
| Memory RAM |
4GB RAM |
| Memory Flash |
64GB ROM |
| Physical |
| AC Adapter |
12V@3A |
| Camera |
Front camera: 8MP |
| Dimensions (mm) |
380.5 (W) x 246.5 (H) x 33 (D) mm |
| Display |
15.6″(1920×1080), capacitive touch screen |
| Interfaces |
1 X USB Type-C, 1 X USB Type-A, 2 X GPIO, 1 X expansion slot, Ethernet RJ45, MicroSD Card support (up to 128GB) |
| Keypad |
Up/down keys, Vol+/VoI-keys, Menu key |
| Modules |
Built in 4G module |
| Notifications |
Speaker and multicolour LEDs |
| Power over Ethernet |
RJ45 IEEE 802.3 af/at |
| Sensors |
Gravity Sensor, Infrared Sensor |
| SIM/TF |
Nano+Nano/Nano+TF |
| Wireless |
| WWAN RADIO |
2G: 850/900/1800/1900MHz; 3G: WCDMA (B1, B2, 85, B8); CDMA: 1X EVDO (BC0); TD-SCDMA: B34/39; 4G: TDD-LTE (B34, B38, B39, B40, 841), FDD-LTE (B1, B2, B3, B5, B7, B8, B20, B28 a&b) |
| WWLAN Radio |
IEEE 802.11 b/g/n/ac, supports 2.4G and 5G dual frequency |
| WPAN RADIO |
Bluetooth 5.2 |
| NFC |
13.56MHz RFID: ISO14443A/B, MIFARE, FeliCa, NFC Forum Tags, ISO15693. Supports ID card reading, supports reader/writer modes. (optional NFC module is required) |
| GPS |
GPS (AGPS), GLONASS, Beidou, Galileo |
| Environmental |
| Operating Temperature |
-10℃ to 50℃ (14°F to 122°F) |
| Storage Temperature |
-20℃ to 60℃ (-4°F to 140°F) |
| Humidity |
5% to 90% (non-condensing) |
| Electro Static Discharge (ESD) |
±12 kV (Air discharge), ±6 kV (Direct discharge) |
| IP Rating |
IP54 (front only) |
| Accessories |
| Optional |
NFC module, MSR module |
| Warranty |
| Standard |
2 years |
| Warranty Extension |
+1 or 3 Years |
| Comprehensive Service |
3 or 5 Years |
