Honeywell 8675i
The Honeywell 8675i is an ultra-rugged, compact wearable scanner designed to bring high-performance hands-free scanning to demanding industrial environments. Built for maximum ergonomics, it easily converts from a low-profile ring scanner to a comfortable back-of-hand glove configuration without tools. Featuring specialized FlexRange™ technology, the device seamlessly reads barcodes near contact out to 33 feet (10 meters), ensuring swift processing of damaged or low-quality labels. Backed by an IP65 sealing rating, heavy tumble specifications, and a hot-swappable smart battery that delivers 12,000 scans per shift, the 8675i minimizes operational downtime and maximizes frontline logistics and warehouse productivity
Description
| MECHANICAL | Dimensions (L x W x H) | 65.2 mm x 30.3mm x 15.2mm (2.6 in x 1.2 in x 0.6in) |
| Weight (Triggered ring with battery) | 8675i-SR: 63g (2.3 oz) • 8675i-FR: 66g (2.4 oz) | |
| Weight (Scanner module only) | 8675i-SR: 50g (1.8 oz) • 8675i-FR: 53g (1.9 oz) | |
| Scan Pattern | Omni-directional area imager | |
| Symbol Contrast | 20% minimum reflectance | |
| Pitch / Skew | +/-60° / +/-60° | |
| Trigger Reliability | Rated for 5 million activation cycles | |
| WIRELESS & POWER | Bluetooth Radio | 2.4 GHz to 2.5GHz ISM Band (Adaptive Frequency Hopping Bluetooth v5.1 Class 1; BLE) |
| Radio Range | 100m (330ft) line of sight | |
| NFC Pairing | Supported (NFC communications for simple tap-to-pair functionality) | |
| Battery Specs | 3.85V, 570mAh • Weight: 19 grams (0.8 oz) | |
| Battery Performance | 12,000 scans over a 10-hour shift | |
| Expected Charge Time | 3.5 hours | |
| ENVIRONMENTAL | Operating Temperature | 8675i-FR & 8675i-SR: -20°C to 50°C (-4°F to 122°F) |
| Storage Temperature | -20°C to 60°C (-4°F to 140°F) | |
| Humidity | 0% to 95% relative humidity (non-condensing) | |
| Drop Resistance | 1.8m (6 ft) Mil-Std-810 Drop Test at operating temperature; 50x 1.5m (5 ft) to concrete at operating temperature | |
| Tumble Resistance | 2,000 tumbles from 0.5 m (1.6 ft) per IEC 60068-2-32 specification | |
| ESD | ±15 kV Air and ±8 kV Direct | |
| Environmental Sealing | Independently certified to meet IP65 standards for moisture and particle intrusion | |
| GLOVE CHARACTERISTICS | Ergonomics | Strap glove securely locates 8675i on back of hand for optimum dexterity, ergonomics, and comfort |
| Durability | Highly durable design for long lifespan, reduced consumable costs | |
| Compatibility | Compatible with bare hand or conventional glove for comfort and user safety | |
| Hand Options | Left and right hand versions available | |
| WARRANTY | Factory Warranty | Two-year factory warranty (Note: Battery warranty is one year) |
